Bidirectional Transmitting BOSA
Model Number: BLBD-PSA-D6120H-55F-2GR(TEC)
Brand Name: Belycomm
Mounting Type: universal type
Description: Pigtail BOSA module
Type: Laser Diode
- Product Introduction
Video Description
Key attributes
| Model Number | BLBD-PSA-D6120H-55F-2GR(TEC) |
| Brand Name | Belycomm |
| Mounting Type | universal type |
| Description | Pigtail BOSA module |
| Type | Laser Diode |
| Place of Origin | Fujian, China |
| Package Type | Through Hole |
| Package / Case | Coaxial |
| Operating Temperature | -20~+70℃ |
| Application | CDMA/GSM transmission system/CATV |
| Supplier Type | original manufacturer, ODM, agency, retailer |
| Media Available | datasheet, Photo |
Packaging and delivery
| Selling Units | Single item |
| Single package size | 29X22.5X5.5 cm |
| Single gross weight | 1.000 KG |
Lead time
| Quantity (pieces) | 1 - 100 | 101 - 1000 | 1001 - 10000 | > 10000 |
| Lead time (days) | 10 | 16 | 18 | To be negotiated |
Specification
Features
1610nm direct modulation with cooled DFB-LD as Transmitter
1550nm InGaAs PIN-PD as Receiver
Low noise, Low distortion Low threshold current
Integrated Optical Isolator
Absolute Maximum Ratings (Tc=25℃)
|
Parameter |
Symbol |
Ratings |
Unit |
Notes |
|
Reverse Voltage(LD) |
Vr(LD) |
2 |
V |
CW |
|
Forward Current(LD) |
If(LD) |
120 |
mA |
CW |
|
Reverse Voltage(MPD) |
Vr(PD) |
15 |
V |
CW |
|
Forward Current(MPD) |
If(PD) |
2 |
mA |
CW |
|
Storage Temperature |
Tstg |
-40~ +85 |
℃ |
- |
|
Operating Temperature |
Topr |
-20~ +70 |
℃ |
- |
|
Lead Soldering Temperature/Time |
Ts |
260/10 |
℃/S |
- |
|
Fiber Yield Strength |
- |
1 |
kgf |
- |
|
Fiber Bend Radius |
- |
30 |
mm |
- |
Transmitter Optical and Electrical Characteristics (Tc=25℃)
|
Parameter |
Symbol |
Min |
Type |
Max |
Unit |
Test Condition |
|
Threshold Current |
Ith |
3 |
15 |
mA |
CW, T=25℃ |
|
|
50 |
mA |
CW, T=85℃ |
||||
|
Forward Voltage |
Vop |
1.2 |
1.5 |
V |
||
|
Optical Output Power |
Po |
2.1 |
3.0 |
mW |
CW, If=30mA |
|
|
Center Wavelength |
λc |
1607 |
1610 |
1613 |
nm |
CW, Po= Pf |
|
Rise time/Fall time |
Tr/Tf |
0.2 |
0.5 |
ns |
If=Ith,Po=Pf, 50 Ohm |
|
|
Monitor Current |
Im |
100 |
1000 |
uA |
CW,Po= Pf |
|
|
Capacitance |
CPD |
10 |
15 |
PF |
VRD=5V,F=1MHz |
|
|
Dark Current |
Id |
100 |
nA |
VRD=5V |
||
|
Spectral Width(RMS-20dB) |
△λ |
0.32 |
0.5 |
nm |
CW, If=30mA |
|
|
Bandwidth |
BW |
2 |
GHz |
|||
|
Slope Efficiency |
SE |
0.09 |
W/A |
CW If=Ith+20mA |
||
|
Tracking Error |
TE |
-1.5 |
1.5 |
dB |
CW, Im=Constant & |
|
|
Isolation |
ISO |
30 |
dB |
|||
|
Side Mode Suppression |
SMSR |
30 |
40 |
dB |
CW, If=Ith+20mA |
|
|
TEC |
Qmax |
0.6 |
W |
|||
|
Imax |
0.9 |
A |
||||
|
Vmax |
1.2 |
V |
||||
|
T |
40 |
K |
||||
|
Thermistor Resistance |
Rth |
9.9 |
kΩ |
|||
|
Relative Intensity Noise |
RIN |
-134 |
dB/Hz |
Receiver Optical and Electrical Characteristics (Tc=25℃)
|
Parameter |
Symbol |
Min |
Type |
Max |
Unit |
Test Condition |
|
Detection range |
λ |
1540 |
1550 |
1560 |
nm |
|
|
Responsivity |
Res |
0.80 |
0.85 |
A/W |
VR=5V,λ=1550 nm |
|
|
Dark current |
Id |
1.0 |
nA |
VR=5V,25°C |
||
|
Bandwidth(-3dB) |
BW |
2.0 |
GHz |
50 Ohm matching |
||
|
Saturation power |
P |
3 |
dBm |
|||
|
Capacitance |
C |
- |
0.6 |
1.0 |
pF |
VR=5V |
|
Rise and Fall time |
Tr/Tf |
- |
0.1 |
- |
ns |
RL=50Ω |
|
IMD2 |
IMD2 |
- |
-70 |
- |
dBc |
λ=1550 nm, (1*) |
|
IMD3 |
IMD3 |
- |
-80 |
- |
dBc |
λ=1550nm, (1*) |
|
Reverse Voltage |
VR |
- |
- |
30 |
V |
|
|
Return Loss |
RL |
40 |
- |
- |
dB |
λ=1550nm |
Outline Diagram and Pin Assignment
